2016 Mercedes-AMG C63 Coupe DTM Technical Specs
C63 Coupe DTM Revealed, Specifications and Gallery Here!

Motorsports

Published on September 5th, 2015 | by Subhash Nair

0

C63 Coupe DTM Revealed, Specifications and Gallery Here!

2016 Mercedes-AMG C63 Coupe DTM Technical Specs
Chassis:
Carbon fibre monocoque with steel roll cage,
front, lateral and rear crash structures,
bonnet, doors, side panels and wings in carbon fibre
c63coupedtm4
Length:
5,010 mm
Width:
1,950 mm
Height:
1,210 mm
Wheelbase:
2,750 mm
Fuel tank:
120 litres
Minimum weight:
1,120 kg
Aerodynamics:
Aerodynamic modifications to front splitter and side panels, flat bottom, front and rear diffusers, rear wing
Engine:
Capacity:
4.0 litres
Cylinder head:
4 valves per cylinder
Cylinder arrangement:
V8, 90°
Performance:
360 KW at 7500 rpm
Maximum torque:
500 Nm
Air intake restrictors:
2 x 28 mm diameter
c63coupedtm3
Transmission:
Standard 6-speed transverse-mounted gearbox, rear-wheel drive, pneumatically operated sequential gear shift on steering wheel, mechanical differential lock without traction control, carbon fibre driveshaft, 3-plate carbon fibre clutch operated by foot pedal
Suspension:
Double wishbones with spring/damper units to front and rear axles, actuated via pushrods
Goodyear f1 650x85(DSF)
Brakes:
Standard carbon braking system without ABS
c63coupedtm1
Steering:
Rack and pinion steering with power assistance
Wheels / tyres:
Aluminium wheels, control tyres
c63coupedtm5
Front: Wheels: 12×18
Tyres: 300 / 680 R18
Rear: Wheels: 13×18
Tyres: 320 / 710 R18
