Hyundai Sonata 2015 Model Specifications


Published on December 11th, 2014 | by Daniel Sherman Fernandez


Hyundai Sonata 2015 Model Specifications


The all-new Hyundai Sonata is available from 15th December at Hyundai showrooms nationwide in 3 variants Elegance B, Elegance and Executive priced from RM138,888  (excluding roadtax and insurance premium).

SPECIFICATIONElegance BEleganceExecutive
Engine2.0 MPi
Displacement (cc)1,999
Bore x Stroke (mm)81 x 97
Compression Ratio10.3
Max Power (ps/rpm)154 / 6,200
Max Torque (Nm/rpm)194 / 4,000
Transmission6 Speed Automatic
Front Wheel DriveStandard
Suspension & Damping
FrontMacPherson Strut
Shock AbsorberAmplitude Selective Damper (A.S.D)
Front Brake TypeVentilated Disc
Rear Brake TypeSolid Disc
Wheels & Tyres
WheelsALLOY 17″ALLOY 18″
Tyres215/55 R17235/45 R18
Safety & Security
Airbag2 (Driver And Front Passenger)6 ( Driver + Front Passenger + Side + Curtain )
Anti-lock Brake System (ABS)Standard
Electronic Stability Control (ESC)Standard
Hillstart Assist Control (HAC)Standard
Steering TypeMotor Driven Power Steering (MDPS)
Tilt & TelescopicManual Tilt & Telescopic
MaterialLeather Wrapped
Overall Steering Gear Ratio14.3
Steering Wheel Turn

(Lock to Lock)

Minimum Turning Radius5.45(m)
Radiator GrilleDark Color Chrome Coating
Door HandleChrome Coated
Head LampProjection Quad-LightBi-Xenon HID Light
SPECIFICATIONElegance BEleganceExecutive
Active Cornering LampN/AStandard
Fog LampRear (LED)
Daytime Running LightsStandard
Rear LampLED Type
Welcome Light Door HandleStandard
Outside MirrorElectric Control & Folding + Side Repeater
Driver Seat12 Way Power Seat

(8 + 4 Way Lumbar Support)

12 Way Power Seat

(8 + 4 Way Lumbar Support)

Front Passenger SeatN/A8 Way Power Seat
Rear Seat FoldingStandard
Supervision Cluster3.5″ OLED ClusterSuper Vision Cluster (4.2″ Color LCD)
Rain SensorN/AStandard
Gear KnobLeather Wrapped
Inside Rear View MirrorDay & NightECM
Rear Console Air VentStandard
Audio SystemRadio+CD+MP3Audio Visual Navigation (AVN)
Steering Wheel Audio ControlStandard
ConnectivityAux+USBAux+USB+Bluetooth+Micro SD Card
Comfort & Convenience
Smart Key with Start Stop ButtonStandard
Smart Trunk SystemStandard
Auto CruiseStandard
Air ConditionDual Zone Auto Air Conditioning
Auto Light ControlStandard
Head Lamp LevellingManualAuto
Head Lamp EscortStandard
Parking AssistRear OnlyFront & Rear
Rear-View CameraN/AStandard
Safety & Security
Safe Drive RecorderN/AStandard
Capacities (liters)
Fuel Tank (liters)70
SPECIFICATIONElegance BEleganceExecutive
Luggage (liters)SAE : 462 / VDA : 510
Exterior dimensions (mm)
Overall length4855
Overall width1865 (excluding door mirrors)
Overall height1475
Front overhang965
Rear overhang1085
Front tread1602-17” / 1597-18”
Rear tread1609-17” / 1604-18”
Interior dimensions (mm)FrontRear
Head Room1025975
Leg Room1155905
Shoulder Room14701435
Note: All figures stated are manufacturer’s estimates
